The thicknesses we offer are the following

Post work offered is the following:

Color can be added and is done in one of two different processes.

1. Polycolor: In which the background or text is the raw aluminum color and whichever is not the raw aluminum color will be dyed.
2. Dye: In whic the background or text is black and whichever is not black will be colored by dye.

The aluminum used is photosensitive anodized aluminum manufactured in the United States as defined by FAR 52.225-1 and Far 252.225-7001 and are anodized per and in accordance with MIL-PRF-8625F, Amendment 2, for sensensitzed plates.

1. MIL-PRF-8625F Amendment 2, Type II, Class 1 &2
2. GG-P-455B (3), Type I, Class 1, Grade A (Prod. Group I) or Class 2, Grade A (Prod. Group III
3. DMS-1674G, Class 1, Type 3 and Class 2
4. MIL-DTL-15024G, Type G
5. MIL-DTL-15024G, Type H (.020 and thicker)
6. MIL-DTL-19834C (0.003", foil)
7. A-A-50271 (Superceding MIL-P-514D), Composition A, Class 2 and Composition C
8. MIL-P-6906B, Type I & II, when the material specified is photosensative aluminum plate

The process we use gives our plates a lifecycle between 20 to 50 years. Polycolor plates may have reduced lifecycles depending on enviromental settings to which they are applied.

Non-colored identification plates have extrmely long lifecycles due to its resistance factors such as:

1. Weather / UV Resistance
2. Abrasion Resistance
3. Temperature Resistance
4. Corrosion Resistance
5. Chemical Resistance

We can create over 100 symbologies below are a few examples:

YES! American Data Plates, Inc. provides professional barcode verification and validation reports, ensuring that all GS1 and other barcodes meet industry standards for scannability, quality, and compliance before final production.

Barcode verification is a critical process that ensures barcodes meet quality standards and can be reliably scanned. Here are some key points about barcode verification:

Purpose: It assesses barcode print quality against industry standards (e.g., ISO/IEC/MIL) to ensure compliance and readability.

• Standards: Common standards include MIL-STD-130, ISO/IEC 15416 for linear (1D) barcodes and ISO/IEC 15415 for two-dimensional (2D) barcodes.

1. Quality Parameters: Key aspects evaluated include symbol contrast, modulation, defects, and decodability.
2. Benefits: Effective verification improves traceability, reduces errors, and ensures compliance with global standards.

Barcode validation is a critical process that ensures the accuracy, readability, and reliability of barcodes used in various industries. It involves several steps to verify that a barcode meets specific standards and can be accurately decoded by scanners. The process includes:

1. Data Integrity Check: Ensuring the data encoded within the barcode is correct and meets the expected format.
2. Format Verification: Confirming the barcode adheres to the standards set for the specific barcode type.
3. Readability Test: Using a barcode scanner to ensure the barcode can be easily read, accounting for variations in scanning technology.
4. Standards Compliance: Ensuring the barcode complies with industry standards like ISO/IEC or GS1.
5. Print Quality: Measuring parameters like edge contrast and modulation to ensure the print quality is sufficient to prevent misreads or no-reads.

By integrating these methods into the validation process, businesses can ensure that their barcodes are reliable and effective, which is crucial for maintaining accurate data in supply chain operations.

American Data Plates, Inc. provides professional barcode verification and validation reports, ensuring that all GS1 and other barcodes meet industry standards for scannability, quality, and compliance before final production.

American Data Plates, Inc. manufactures various types of panels. From using photosensetive aluminum to UV-stable reversed texture impact modified acrylic.

Sizes vary to your specifications.

Photosensitive aluminum panels have a maximum size of 20.0" x 12.0"

All of our panels are either made with aluminum or UV-stable reversed texture impact modified acrylic.

Yes all our panels have the ability to be cut to your specifications by either Milling or by Laser

Post work offered is the following:

Panels utilizing our photosenitive aluminum retain a life cycle of 20 -50 years depending on environmental conditions.

Our UV-stable reversed texture impact modified acrylic has a normal life cycle of 10-15 years.

Our labels and placards can be manufactured from the following materials:

1. Photosensative Aluminum
2. Autotex - Polyester
3. Autoflex - Polyester
4. Polycarbonate
5. Vinyl

Our aluminum labels are manufactured with photosensitive aluminum which have a life cycle of 20 - 50 years.

They can be manufactured standard which is black and raw aluminum output, or with Polycolor to give a single color background with raw aluminum color text, or color text with raw aluminum background.

The materials used for labels and placards have the following thicknesses and finishes in which are not limited to:

Post work offered is the following:

The following are the life cycles of labels and placards per their base material. ⚠️ Remember all life cycles can be affected by environmental conditions surrounding the label and placard.

** Vinyl is not suitable for outdoor labeling or when environmental conditions include extreme heat.

At the current time American Data Plates, Inc. can part mark any part that has a flat surface. We currently run part marking using a CO2 laser, and can engrave or mark on Aluminum, Steel, Titanium, Brass, and more metals.

We cannot part mark any recessed areas due to restraints with our current CO2 lasers. Partner and Client wide notification will be sent upon converting to fiber lasers.

MIL-STD-130

MIL Standard to Laser Part Marking

The MIL-STD-130 standard outlines the requirements for marking and tracking military property, including the use of Unique Item Identifiers (UID) for permanent identification. Laser marking systems are a key component of this standard, providing high-speed, high-precision engraving that fully meets UID compliance standards. These systems ensure that markings are durable, legible, and can withstand the extreme conditions typical of defense applications. By adhering to MIL-STD-130, manufacturers can ensure that their products are traceable and compliant with DoD specifications, which is crucial for maintaining operational readiness and combat readiness.

Currently we can mark parts that meet the following dimensions:

54.0" X 35.0" or under

We currently use 150W CO2 Lasers for our part marking, but are currently forecasting to convert to 60W Fiber Lasers for part marking.

The durability of a laser engraving can exceed 30 years, and in many cases, it is permanent. On materials like stainless steel, aluminum, or titanium, engravings can last for the entire lifetime of the item without noticeable wear. On plastics or softer surfaces, the lifespan may be shorter, but it still outlasts most traditional marking methods.

American Data Plates, Inc. Currently holds for the following Certifications:

• ISO9001:2015 / AS9100D

Due to NADCAP Exemption for our photosensitive aluminum the NADCAP certification is not required.

The ISO 9001:2015 and AS9100D certifications (held jointly by American Data Plates, Inc.) significantly strengthen the company's operations, product reliability, and market position—particularly in the high-stakes aerospace, defense, space, and military sectors where durable identification solutions like data plates, UID/IUID tags, nameplates, and overlays are critical for safety, traceability, and compliance.

Foundational Role of ISO 9001:2015

ISO 9001:2015 provides the universal baseline for a robust Quality Management System (QMS). It emphasizes customer focus, leadership, process approach, improvement, evidence-based decision making, and relationship management. For American Data Plates, this translates to:

• Standardized processes that ensure consistent quality in manufacturing (e.g., photosensitive aluminum plates, screen/UV printing, and custom fabrication).
• Reduced errors, waste, and variability through documented procedures, internal audits, and continual improvement.
• Enhanced customer satisfaction by systematically addressing requirements and feedback.
• Greater operational efficiency and data-driven decisions, which support on-time delivery and near-zero defect rates.

This certification alone signals a professional, reliable QMS that applies across industries.

Aerospace-Specific Enhancements from AS9100D

AS9100D builds directly on ISO 9001:2015 (incorporating ~75% of its requirements) while adding over 100 tailored requirements for the Aviation, Space, and Defense (AS&D) industries. It is the internationally recognized QMS standard for these sectors, often required by primes, DoD, NASA, FAA, and major contractors.

Key ways AS9100D enhances American Data Plates, Inc.:

• Risk-Based Thinking and Mitigation — Stronger emphasis on identifying, assessing, and managing risks throughout operations—including operational, product safety, and supply chain risks. This reduces the likelihood of failures in mission-critical marking solutions exposed to extreme environments (e.g., aerospace platforms).
• Product Safety and Counterfeit Parts Prevention — Explicit requirements for preventing counterfeit or suspect parts (Clause 8.1.4), including controls on suppliers, traceability, verification methods, obsolescence monitoring, and employee training. For data plates and UID tags, this ensures materials and processes deliver authentic, compliant products that support long-term asset tracking and regulatory adherence (e.g., MIL-STD-130).
• Configuration Management — Rigorous controls to maintain product definition and integrity across the lifecycle. This is vital for custom identification products that must match exact customer drawings, revisions, and specifications without deviation.
• Enhanced Traceability and First Article Inspection (FAI) — Improved requirements for full traceability (from raw materials to finished plates) and structured verification processes, aligning perfectly with UID/IUID marking and serialized solutions.
• Supplier and External Provider Controls — Stricter evaluation and monitoring of the supply chain, minimizing risks from sub-tier providers and ensuring only approved, high-quality inputs are used.
• Operational Discipline and Consistency — Formalized processes for project management, work transfers, key characteristics, and foreign object debris (FOD) prevention where relevant. This leads to higher reliability, fewer nonconformances, and better performance in demanding environments.

Overall Business and Customer Benefits

Holding both certifications (with AS9100D encompassing and exceeding ISO 9001:2015) provides American Data Plates, Inc. with:

• Competitive Advantage and Market Access — Many aerospace/defense contracts and suppliers require AS9100D as a prerequisite. It positions the company as a trusted, preferred vendor in the Palmdale/Lancaster aerospace corridor and beyond.
• Improved Efficiency and Cost-Effectiveness — Reduced waste, rework, and quality costs through proactive process controls and continuous improvement.
• Higher Customer Confidence and Satisfaction — Demonstrates commitment to excellence, safety, and reliability—critical when products support equipment traceability, safety labeling, and regulatory compliance for U.S. military and high-reliability programs.
• Reputation and Brand Strength — Signals leadership in quality, helping win bids, build long-term relationships with primes, and differentiate from non-certified competitors.
• Internal Culture — Fosters a more engaged workforce focused on accountability, data-driven decisions, and ongoing enhancement.

In short, ISO 9001:2015 establishes a solid, general-purpose quality foundation, while AS9100D elevates it to aerospace-grade rigor. Together, they enable American Data Plates, Inc. to deliver durable, compliant, Made-in-USA identification products with the consistency, traceability, and risk controls that defense and aerospace customers demand—ultimately supporting mission success with fewer defects and greater reliability.

Currently Held Certifications (as of 2026)

American Data Plates, Inc. maintains the following active certifications:

• AS9100D (Aerospace Quality Management System) This is the gold-standard QMS for aviation, space, and defense industries. It builds on ISO 9001:2015 with additional requirements for risk management, product safety, counterfeit parts prevention, configuration management, and traceability.
• ISO 9001:2015 (Quality Management System) The international baseline for consistent quality processes, customer satisfaction, and continual improvement. AS9100D incorporates and exceeds this standard.

These dual certifications demonstrate a rigorous, auditable quality system that supports zero-defect performance, on-time delivery, and full traceability—critical for manufacturing durable data plates, UID/IUID tags, nameplates, panels, and overlays.

Compliance Standards & Requirements (Not Formal Certifications, But Mandatory for Our Work)

To serve aerospace, defense, and military customers, American Data Plates must comply with these key standards (they explicitly reference expertise in them):

• MIL-STD-130 (Identification Marking of U.S. Military Property) — The primary DoD standard for item marking. Requires permanent, legible markings including Unique Item Identification (UID/IUID) with 2D Data Matrix barcodes. They perform ISO/IEC 15415-compliant verification on every UID mark they produce.
• MIL-DTL-15024 and related specs (e.g., MIL-DTL-19834 for adhesive-backed foil plates) — General requirements for military nameplates, instruction plates, and identification hardware.
• ITAR / EAR Compliance — Strict adherence to export controls for defense-related articles and technical data (mentioned in their mission and operations).
• DFARS clauses (e.g., 252.211-7003 for Item Unique Identification) — Required when supplying to DoD contracts involving qualifying items (typically $5,000+ or mission-critical).

We also support compliance with broader requirements such as:

• First Article Inspection (FAI)
• Counterfeit parts prevention
• Full material and process traceability

Are These Certifications “Required”?

It depends on the customer and contract:

Bottom line: AS9100D + ISO 9001:2015 are the core formal certifications that give American Data Plates, Inc. a strong competitive edge and are effectively required (or highly preferred) for most aerospace and defense work. MIL-STD-130 expertise and ITAR compliance are operational necessities rather than standalone “certifications.”

Maintaining these demonstrates our commitment to the highest levels of quality, safety, and reliability demanded by U.S. military and high-reliability programs.

Employee Training, Certification & Recertification

At American Data Plates, Inc., our greatest asset is our skilled and highly trained workforce. We maintain a rigorous employee certification and recertification program that ensures every team member is fully qualified to operate equipment, execute processes, and uphold the exacting standards required for aerospace, defense, and high-reliability identification products.

This program is a cornerstone of our AS9100D-certified Quality Management System and directly supports our zero-tolerance rejection policy and commitment to delivering near-perfect, mission-critical data plates, UID/IUID tags, nameplates, panels, and overlays.

Comprehensive Certification Process

All employees undergo structured, documented training and certification before being authorized to work independently on production equipment or processes. Key areas of certification include:

• Advanced Tooling Operation
  • 150W CO₂ and Fiber Laser systems (marking, etching, and cutting)
  • Pneumatic tooling and presses
  • Drill presses and precision drilling operations
  • Foot shears and material cutting equipment
  • Metalphoto® processing lines (exposure, development, and sealing)
  • UV and screen printing systems
  • Precision measuring tools and UID barcode verifiers
• Manufacturing Processes
  • Photosensitive anodized aluminum imaging and finishing
  • UID/IUID 2D Data Matrix code generation and verification (ISO/IEC 15415 compliant)
  • MIL-STD-130 compliant marking and labeling
  • Configuration management and revision control
  • First Article Inspection (FAI) procedures
  • Counterfeit parts prevention and material traceability protocols
• Quality & Compliance
  • AS9100D / ISO 9001:2015 quality procedures and documentation
  • Risk identification and mitigation
  • Nonconformance reporting and root cause corrective action (RCCA)
  • Product safety and foreign object debris (FOD) prevention

Recertification & Continuous Competency

To maintain the highest level of proficiency and adapt to evolving requirements, American Data Plates, Inc. enforces a formal recertification program. Employees are periodically re-evaluated and recertified on:

• Equipment operation and safety
• Process changes or improvements
• Updated customer specifications or military standards
• New tooling or software implementations
• Refresher training on quality clauses and compliance topics

Recertification intervals are determined by process criticality, equipment complexity, and performance data. Any observed deviations trigger immediate retraining and re-evaluation before the employee returns to production.

Benefits to Customers and Mission Success

This disciplined approach to employee development delivers measurable advantages:

• Consistent, repeatable quality across all shifts and production runs
• Reduced process variation and human error
• Faster onboarding of new team members while maintaining standards
• Stronger traceability and audit readiness for DoD, prime contractors, and aerospace customers
• Higher employee engagement and ownership of quality outcomes

By investing in continuous training and certification, American Data Plates, Inc. ensures that every data plate, UID tag, and panel leaving our Palmdale, California facility reflects the expertise, precision, and professionalism of a fully qualified team operating under AS9100D rigor.

Our certified workforce is one of the primary reasons we can confidently uphold our zero-tolerance rejection policy and serve as a trusted partner to the United States Military and high-reliability programs.

Certifications Recognized by Customers

• AS9100D (Aerospace Quality Management System) Certificate Number: 1120085 This is the most widely recognized and often contractually required certification for suppliers to the aviation, space, and defense industries. It demonstrates a robust Quality Management System (QMS) with aerospace-specific requirements for risk management, product safety, configuration management, counterfeit parts prevention, and traceability. Many prime contractors and DoD programs list AS9100D as a prerequisite for approval on their supplier lists.
• ISO 9001:2015 (Quality Management System) AS9100D builds directly on and exceeds ISO 9001:2015. Customers in both defense and commercial high-reliability sectors recognize this as the foundational standard for consistent processes, continual improvement, and customer satisfaction. Holding both certifications together signals mature, auditable quality controls.

These two certifications are prominently featured on the company website and are frequently cited as key reasons customers trust American Data Plates, Inc. for mission-critical identification solutions.

Key Compliance Standards & Expertise Highly Valued by Customers

While not always formal “certifications,” the following are actively recognized and verified by customers during source selection, audits, and incoming inspection:

• MIL-STD-130 (Identification Marking of U.S. Military Property) Expertise in this DoD standard is essential for all UID/IUID marking. American Data Plates performs 100% in-house verification of every 2D Data Matrix code to ISO/IEC 15415 standards, ensuring Grade B (or higher) quality, syntax compliance, and long-term machine readability. This prevents DCMA rejections, WAWF issues, and audit findings for military property.
• MIL-DTL-15024 and related military specifications (e.g., MIL-DTL-19834) Compliance with these governs the design, materials, and durability of nameplates, instruction plates, and identification hardware used on military equipment.
• DFARS Clauses (e.g., 252.211-7003 – Item Unique Identification and Valuation) Customers in DoD supply chains require adherence to these clauses for qualifying items.
• Counterfeit Parts Prevention & Material Traceability Built into the AS9100D QMS, this aligns with AS&D industry requirements and is a major concern for primes and government buyers.
• First Article Inspection (FAI) per AS9102 Supported when required by customer contracts.

How These Certifications Benefit Customers

Additional Customer Expectations

• ITAR / Export Compliance — For defense-related technical data and products.
• Made in the USA with domestic materials — Preferred or required by many DoD and government programs.
• Zero-defect performance and on-time delivery — Enabled by the AS9100D QMS and employee training/recertification programs.

Bottom line: AS9100D (with ISO 9001:2015) is the flagship certification most recognized and required by your core aerospace and defense customers. Combined with proven MIL-STD-130 expertise and UID verification capabilities, these give American Data Plates, Inc. strong credibility when bidding on or supplying to military programs, prime contractors, and high-reliability platforms.

Customers view these as evidence of a mature, risk-mitigated supplier capable of delivering permanent, compliant identification solutions that support equipment safety, traceability, and lifecycle management without issues.

CAPABILITIES STATEMENT

American Data Plates, Inc. 410 Grand Cypress Avenue, Suite 202 Palmdale, California 93551 Phone: (661) 723-0942 Website: www.americandataplatesinc.com UEI: K9MUG33TPXF3 | CAGE: 8EQ56

Woman-Owned Small Business (WOSB)

Company Overview

American Data Plates, Inc. is a premier manufacturer of high-precision identification solutions, specializing in data plates, nameplates, UID/IUID tags, panels, overlays, placards, and labels. Since 1995, we have delivered durable, compliant marking products engineered for the most demanding environments in aerospace, defense, space, energy, and heavy industry.

Our zero-tolerance rejection policy and rigorous quality processes ensure every product meets or exceeds customer specifications and arrives on time, allowing our partners to focus on mission-critical operations. We are proud to support the United States Military and Defense community as our primary focus, while serving prime contractors and suppliers across high-reliability sectors.

Core Capabilities

• MIL-STD-130 Compliant UID/IUID Marking — Permanent 2D Data Matrix codes and Unique Item Identification for full lifecycle asset tracking, traceability, and automatic data capture.
• Identification Plates & Nameplates — Photosensitive aluminum and other substrates engineered for 20–50+ year durability in extreme conditions.
• Panels, Overlays & Placards — Custom instructional, safety, and regulatory-compliant overlays and panels.
• Labels & Part Marking — High-performance labels, barcode solutions (verification for 32+ symbologies), and serialized marking.
• Materials & Processes — Metalphoto, screen print, UV print, large-format printing, and custom fabrication to exact customer drawings and specifications.
• Compliance & Certification — Products designed to meet DoD, aerospace, and agency regulatory requirements. AS9100D / ISO 9001:2015 certified Quality Management System.

All products are Made in the USA using domestic raw materials.

Past Performance & Differentiators

• Decades of experience supporting U.S. military programs, aerospace platforms, and defense contractors with classified or sensitive marking solutions.
• Exceptional quality focus with near-zero defects, on-time delivery, and full traceability.
• Located in Palmdale, California — the heart of America’s aerospace and defense innovation corridor.
• Versatile in-house equipment enables rapid prototyping to full production runs.

NAICS Codes

• 339999 — All Other Miscellaneous Manufacturing (Primary)
• Additional relevant codes: 332812, 332999, 323111, and related manufacturing/printing codes

Certifications

• AS9100D / ISO 9001:2015 Certified

American Data Plates, Inc. is committed to delivering superior, mission-ready identification and marking solutions that enhance equipment traceability, safety, and compliance for the Department of Defense and federal agencies.

Ready to partner on your next program.

Manufacturing Tooling & Equipment Capabilities

American Data Plates, Inc. maintains a versatile, in-house manufacturing facility in Palmdale, California, equipped with modern and specialized tooling that enables precise, repeatable production of high-durability data plates, nameplates, UID/IUID tags, panels, overlays, placards, and labels. This combination of advanced and traditional equipment supports everything from rapid prototyping to full-scale production while upholding our zero-tolerance rejection policy and AS9100D/ISO 9001:2015 quality standards.

Key Tooling and Equipment Include:

• 150W CO₂ Lasers High-power laser systems provide clean, permanent marking, etching, and cutting on a wide range of substrates, including photosensitive anodized aluminum (Metalphoto®), stainless steel, and other metals. These lasers deliver precise serialization, 2D Data Matrix UID codes, barcodes, and fine graphics with excellent edge definition and depth control. They are essential for MIL-STD-130 compliant markings that withstand extreme aerospace, defense, and industrial environments for decades.
• Pneumatic Tooling Precision pneumatic presses, applicators, and assembly tools enable consistent, high-volume processing of adhesive-backed plates, rivet installation, and forming operations. Pneumatic systems deliver controlled force and speed, reducing operator variability and ensuring repeatable quality on high-reliability components.
• Drill Presses Heavy-duty and precision drill presses (including multi-spindle configurations) support accurate hole drilling, countersinking, and mounting preparation required for secure installation of data plates and panels on equipment, aircraft, vehicles, and machinery.
• Foot Shears Manual and powered foot shears provide clean, straight, and burr-free cutting of sheet materials such as aluminum, stainless steel, and foil. This equipment allows efficient material sizing and custom fabrication while maintaining tight tolerances for both prototype and production runs.

Additional Supporting Equipment & Processes:

• Large-format UV and screen printing systems for high-resolution graphics and multi-color overlays.
• Metalphoto® processing lines (exposure, development, and sealing) for ultra-durable, photographically imaged plates.
• Precision measuring and verification tools, including UID barcode verifiers compliant with ISO/IEC 15415 and MIL-STD-130 requirements.
• Forming, punching, and finishing stations for custom shaping and edge treatment.

This diverse tooling portfolio gives American Data Plates, Inc. full vertical integration—from raw material preparation and imaging to final fabrication, marking, and quality verification. Located in the heart of Southern California’s aerospace corridor, our equipment and skilled team enable fast turnaround, strict configuration management, and the exceptional durability demanded by U.S. military, defense primes, NASA, and high-reliability commercial programs.

All processes are performed under our AS9100D-certified Quality Management System, ensuring traceability, risk mitigation, and consistent delivery of mission-critical identification solutions with near-zero defects.

Quality Assurance in Manufacturing

American Data Plates, Inc. is deeply committed to delivering zero-defect, mission-critical identification solutions through a rigorous, end-to-end Quality Management System (QMS). Every data plate, UID/IUID tag, nameplate, panel, overlay, and label we produce is manufactured under strict controls to ensure permanent legibility, exceptional durability, and full regulatory compliance in the harshest aerospace, defense, and industrial environments.

Our zero-tolerance rejection policy means that nonconforming products are never shipped. Instead, issues are systematically identified, root-caused, and eliminated through continuous improvement—resulting in near-perfect on-time delivery and customer satisfaction for U.S. military programs and high-reliability contractors.

AS9100D & ISO 9001:2015 Certified Quality Management System

American Data Plates, Inc. maintains AS9100D certification (Certificate Number: 1120085) along with ISO 9001:2015 registration. AS9100D is the internationally recognized Quality Management System standard specifically developed for the Aviation, Space, and Defense (AS&D) industries. It builds upon and significantly strengthens the foundational requirements of ISO 9001:2015 by adding more than 100 aerospace-specific clauses.

Key elements of our AS9100D-driven QMS include:

• Risk-Based Thinking — Proactive identification, assessment, and mitigation of risks at every stage—from material selection and supplier evaluation to production, inspection, and delivery. This minimizes the potential for failures in critical marking and asset-tracking applications.
• Product Safety & Counterfeit Parts Prevention — Robust controls to prevent the introduction of counterfeit or suspect materials, including supplier verification, traceability protocols, employee training, and obsolescence management.
• Configuration Management & Traceability — Strict adherence to customer drawings, revisions, and specifications. Full material and process traceability from raw stock through final product ensures compliance with MIL-STD-130, MIL-DTL-15024, and DFARS requirements.
• First Article Inspection (FAI) & Verification Processes — Detailed inspection and testing, including ISO/IEC 15415-compliant UID barcode verification on every 2D Data Matrix code we produce.
• Supplier & External Provider Controls — Rigorous evaluation and ongoing monitoring of our supply chain to guarantee only approved, high-quality inputs are used.
• Continual Improvement & Evidence-Based Decision Making — Regular internal audits, management reviews, and data-driven process enhancements that drive operational efficiency and reduce waste.
• Operational Discipline — Standardized work instructions, controlled manufacturing environments, and disciplined handling, storage, and shipping practices that protect product integrity.

How This Translates to Superior Manufacturing Quality

Our AS9100D-certified QMS directly supports the precision manufacturing of durable identification products using advanced tooling such as 150W lasers, pneumatic presses, drill presses, foot shears, Metalphoto® processing, and UV/screen printing systems. Every step is documented, measured, and verified to ensure:

• Consistent, repeatable results across prototype to high-volume production runs.
• Exceptional durability (20–50+ years in extreme conditions).
• Full compliance with DoD, aerospace, and customer-specific standards.
• Tamper-resistant, permanent markings that support accurate asset tracking and lifecycle management.

Located in Palmdale, California—the heart of America’s aerospace corridor—our quality culture is reinforced by skilled craftsmanship, ethical leadership, and a relentless customer-first philosophy.

“Strategic Precision” is more than a tagline at American Data Plates, Inc. It is the guiding principle behind every plate we produce and every process we refine under our AS9100D QMS.

This commitment to quality enables us to serve as a trusted partner to the U.S. Military, prime contractors, NASA, and high-reliability programs—delivering identification solutions that enhance safety, traceability, and mission success with uncompromising reliability.

Identification Solutions

American Data Plates, Inc. delivers precision-engineered identification and marking solutions that ensure long-term durability, regulatory compliance, and reliable asset traceability for the most demanding environments. Our comprehensive portfolio supports the United States Military, defense primes, aerospace, space, energy, and heavy industry customers who require permanent, legible, and tamper-resistant products that perform for 20–50+ years.

We specialize in MIL-STD-130 compliant solutions with full Unique Item Identification (UID/IUID) capabilities, including in-house ISO/IEC 15415 barcode verification across more than 32 symbologies.

Core Solutions We Provide:

• Data Plates & Nameplates High-durability identification plates produced primarily on photosensitive anodized aluminum (Metalphoto®) for exceptional resolution and resistance to abrasion, chemicals, UV exposure, and extreme temperatures. Custom variable data, serialization, barcodes, and UID 2D Data Matrix codes are integrated directly into the plate. Available with holes for mechanical mounting or adhesive backing for quick installation. Designed to meet MIL-DTL-15024 and other military specifications.
• UID / IUID Tags & Marking Solutions Permanent Unique Item Identification tags and direct part marking that enable full lifecycle tracking, automatic data capture, and inventory management for weapons systems, aircraft, vehicles, ground support equipment, and critical components. Every UID mark undergoes rigorous verification to ensure compliance with DoD requirements (DFARS 252.211-7003).
• Panels & Overlays Custom instrument panels, control panels, instructional overlays, and multi-layer assemblies. Options include backlit designs, screen printing, UV digital printing, and precise cutouts for gauges, switches, and indicators. Ideal for operator interfaces in aerospace, automotive, and industrial equipment.
• Placards & Labels Safety placards, warning labels, instructional placards, and high-performance adhesive or mechanical labels. These solutions provide clear communication for maintenance, operation, and regulatory compliance while withstanding harsh operational conditions.
• Part Marking & Barcode Solutions Serialized part marking, high-resolution barcoding, and large-format printing for components and sub-assemblies. Our advanced processes support rapid prototyping, short runs, and full production volumes with consistent quality.

Key Features of All Our Solutions:

• Exceptional Durability — Products engineered for decades of service in extreme environments (aerospace, defense, outdoor, and industrial).
• Full Customization — Built exactly to customer drawings, revisions, and specifications with strict configuration management.
• Compliance & Traceability — MIL-STD-130, AS9100D/ISO 9001:2015 certified processes, full material traceability, and counterfeit parts prevention.
• Ready-to-Install — Plates and labels arrive complete with required mounting features (holes, adhesive, or other) and zero defects under our strict rejection policy.
• Made in the USA — Domestic manufacturing in Palmdale, California, using high-quality materials and advanced tooling including 150W lasers, pneumatic systems, and precision fabrication equipment.

Whether you need a single prototype UID tag for a new program or thousands of durable nameplates for a major platform sustainment effort, American Data Plates, Inc. provides turnkey identification solutions that reduce risk, enhance safety, improve traceability, and free your team to focus on mission-critical work.

Our zero-tolerance rejection policy and AS9100D-certified Quality Management System ensure every solution arrives on time, meets spec, and performs reliably—supporting the success of U.S. defense programs and high-reliability applications.

To begin an order, please request an RFQ (request Formal Quote), through either here on our website, or through email also on our contacts page.

To properly ensure the RFQ is fulfilled properly, please when requesting also required will be a engineering drawing of the part you are requesting the RFQ if the part has not been manufactured by American Data Plates, Inc. before.

All orders must be placed with a purchase order, we cannot accept email order requests. Please submit your purchase order after you have recieved your RFQ from American Data Plates, Inc.

All purchase orders must include a ship date, or dock date.

All orders are accompanied with the following certificates:

1. Material Manufacturer Certifications
2. American Data Plates, Inc. Certificate of Conformace
3. Barcode Verification / Validation Reports (If required)

Turna around times and shipping

Standard Manufacture time: 6 - 8 business days excluding Fridays. ADPI is open Monday through Thursday.

Expedites are available, please inquire when submitting for an RFQ if expedited option may be required.

Document Retention

American Data Plates, Inc. retains all documents and certificates for a period of 10 years from the date of receiving purchase order(s).
